TOMZN Adjustable Voltage and Ampere Protection Breaker 63A (TOVPD1-60-EC)
The TOMZN TOVPD1-60-EC is an adjustable digital power protector designed to safeguard sensitive home and industrial appliances from damage caused by harmful electrical anomalies. Featuring clear digital displays for real-time voltage and current monitoring, it provides fully customizable over-voltage, under-voltage, and over-current protection with rapid tripping response times as fast as 0.1 seconds. It is ideal for safeguarding entire distribution boards, air conditioners, refrigerators, and heavy motor loads by cutting off power before voltage surges or drops can ruin internal electronics. Equipped with automatic recovery and power-on delay functions, it ensures seamless continuity and essential safety against the frequent voltage fluctuations and power surges typical of Pakistan's local power grid.
Specifications
- Model
- TOVPD1-60-EC
- Rated Voltage
- 230VAC (50/60Hz)
- Max Current / Load
- 1A–40A or 1A–63A (Adjustable)
- Protection Types
- Over-Voltage, Under-Voltage, Over-Current
- Tripping Time / Response Time
- 0.1s–30s (Adjustable, Default: 0.5s)
- Display Type
- Digital Display (Voltage & Current Measurement)
- Over-Voltage Protection Range
- 230V–300V–OFF (Default: 270V)
- Under-Voltage Protection Range
- 140V–210V–OFF (Default: 170V)
- Over-Current Protection Range
- 1A–40A / 1A–63A (Adjustable)
- Recovery Delay Time
- 1s–500s (Default: 30s)
- Power-On Delay Time
- 1s–500s (Default: 10s)
- Power Consumption
- < 2W
- Electrical / Mechanical Life
- 100,000 cycles
- Installation Type
- 35mm DIN Rail
